Overview
Brand: Hughes Performance
Manufacturer’s Part Number: 35-3
Part Type: Automatic Transmissions
Product Line: Hughes Performance Street and Strip Transmissions
Summit Racing Part Number: HUP-35-3
Number of Gears: 3
Bellhousing Bolt Pattern Manufacturer: Chevy
Transmission Shift Pattern: Reverse
Valve Body Style: Full manual
Transmission Advertised Horsepower Rating: 650
Torque Converter Included: No
Flexplate Included: No
Transmission Controller Included: No
Wiring Harness Included: No
Transmission Cooler Included: No
Trans-Brake Included: Yes
Lockup Compatible: No
Transmission Pan Style: Stock
Transmission Pan Material: Aluminum
Transmission Pan Finish: Chrome
Tailshaft Length (in.): 6.000 in.
Yoke Style: Slip-on
Input Spline Quantity: 30
First Gear Ratio (Automatic Transmissions): 2.52
Transmission Case Style: OEM
Transmission Case Material: Aluminum
Transmission Case Finish: Black
Transmission Shield Built In: No
Flexplate Shield Built In: No
Fluid Fill Location: Case
Transmission Fluid Included: No
Dipstick Included: No
Remanufactured: Yes
Quantity: Sold individually.
Notes: Operation of reverse gear requires depression of trans. brake button.
Hughes Performance Street and Strip Transmissions
Hughes Performance Street and Strip transmissions are made tough enough to deliver tire-spinning shifts race after race. They include internal and external racing components, which increase strength, reliability, and torque capacity. Plus, they feature Hughes’ manual/automatic valve body to provide precise manual or fully automatic shifting. Choose the transmission type best suited for your vehicle.
