Ironton OHV Horizontal Engine 208cc, 3/4in. 19.05mm x 2 19/64in. 58.5mm Shaft
Product Summary
This Ironton OHV Horizontal Engine is an easy-to-install solution for small engine needs. With 208cc and 9 ft.-lbs. Gross Torque/12.5N.m/2,800rpm engine torque, this 500-hour engine provides enough power to run a wide range of equipment, including log splitters and pressure washers. Its design incorporates a cast iron cylinder sleeve and dual ball bearing crankshafts. Low-oil shutdown turns the engine off if it runs low on oil, preventing serious damage or failure. The recoil start has a compression release that helps you get ruing on the first pull.n
Key Specs
| Item# | 45751 |
| Brand | Ironton |
| Manufacturer’s Warranty | 3 months parts / 3 months labor |
| Ship Weight | 37.4 lbs |
| Engine Displacement | 208 cc |
| Engine Type | OHV |
| Start Type | Recoil |
| Shaft Diameter | 3/4 in |
| Shaft Length | 2.29 in |
| Shaft Diameter Metric | 19.05 mm |
| Shaft Length Metric | 58.5 mm |
| Shaft Output | Horizontal |
| Shaft Keyway | 0.19 in |
| Shaft Rotation (From PTO Shaft Side) | Counterclockwise |
| PTO Height | 4.17 in |
| Cylinders (qty.) | 1 |
| Cylinder Bore | Cast iron |
| Cooling System | Air cooled |
| Air Cleaner Type | Pleated paper w/foam pre-cleaner |
| Fuel Tank Capacity | 3.38 qt |
| Oil Capacity | 0.5 qt |
| Low Oil Alert | Yes |
| Lubrication System | Splash |
| Ignition System | Electronic |
| Governor System | Mechanical |
| Carburetor | Float/choke |
| Max. RPM | 3,800 |
| Muffler Included | Yes |
| CARB Approval | No |
| Bolt Circle | 3.625 in |
| Mounting Base Length | 6.4 in |
| Mounting Base Width | 3.07 in |
| Dimensions L x W x H (in.) | 16.5 x 15 x 14.8 in |
