Honda GXV340 DE33 / GXV340UT2DE33 337 cc 8.9 Net HP Vertical Engine, 1 inch x 3.13 inch Crankshaft, 12V Electric Start with 3A Alternatorn
Key Specifications
| BRAND | Honda |
|---|---|
| MODEL NUMBER | GXV340-DE33 |
| WARRANTY | 3 Year Consumer & Commercial |
| SHIPPING WEIGHT | 87 |
| DISPLACEMENT | 337cc |
| STARTER TYPE | Electric & Recoil |
| CRANKSHAFT ORIENTATION | Vertical |
| CRANKSHAFT TYPE | Straight |
| FUEL SYSTEM | Gasoline |
| GEAR REDUCTION | No |
| CRANKSHAFT DIMENSIONS | 1″ x 3.13″ |
| CRANKSHAFT LENGTH | 3.13″ |
| CRANKSHAFT END TAPPED SIZE | 7/16 – 20 |
| CRANKSHAFT KEYWAY WIDTH | 1/4″ |
| CRANKSHAFT ROTATION DIRECTION (FROM PTO SIDE) | Counterclockwise |
| CYLINDERS | 1 |
| CYLINDER BORE TYPE | Cast Iron |
| AIR CLEANER TYPE | Dual Element |
| FUEL PUMP | No |
| OIL COOLER | No |
| OIL CAPACITY | 39 |
| LOW OIL ALERT | No |
| LOW OIL SHUTDOWN | No |
| IGNITION SYSTEM | Transistorized Magneto |
| CARBURETOR TYPE | Float |
| CHOKE CONTROL | Remote (Wire) |
| BOLT CIRCLE | 10 |
| NOTES | Engine Notes: |
| PTO HEIGHT | N/A |
