The Honda 270cc GX Series OHV commercial-grade engine is designed for the most demanding commercial applications. It is reliable and durable, with an overhead valve design for cooler, fuel-efficient operation, and a cast iron cylinder sleeve for longer service life. Great for construction equipment and can also be used in cement mixer applications.n
| Item# | 75923 |
| Brand | Honda Engines |
| Manufacturer’s Warranty | 3 year limited warranty |
| Ship Weight | 80.0 lbs |
| Engine Displacement | 270 cc |
| Engine Type | GX Series OHV commercial-duty |
| Net Power Output | 8.5 HP |
| Start Type | Recoil |
| Shaft Diameter | 1 in |
| Shaft Length | 3.23 in |
| Net Torque | 14.1 ft-lbs. |
| Shaft Output | Horizontal |
| Shaft End Tapped (Diameter (in.)/Threads per inch) | M8 x 1.25 |
| Shaft Rotation (From PTO Shaft Side) | Counterclockwise |
| Crankshaft | R-type |
| PTO Height | 5.25 in |
| Bearing Type | Ball |
| Cylinders (qty.) | 1 |
| Cylinder Bore | Cast iron |
| Compression Ratio | 8.5:1 |
| Cooling System | Air cooled |
| Bore | 3 in |
| Stroke | 2.3 in |
| Air Cleaner Type | Dual element |
| Fuel Tank | No |
| Fuel Type | Gasoline |
| Oil Capacity | 1.16 qt |
| Low Oil Alert | Yes |
| Lubrication System | Splash |
| Ignition System | Electronic |
| Governor System | Centrifugal mechanical |
| Carburetor | Float, external vent |
| Throttle Control | Remote (wire) |
| Choke Control | Manual |
| Max. RPM | 3,600 |
| Muffler Included | Yes |
| Auto Compression Release | Yes |
| CARB Approval | No |
| Bolt Circle | 5, 6.5 in |
| Mounting Base Length | 7.68 in |
| Mounting Base Width | 3.18 to 3.68 in |
| Product Weight | 75 lb |
| Dimensions L x W x H (in.) | 15 x 16.87 x 16.12 in |
