Operating Weight – Nominal8270 kg
Operating Weight – Maximum11000 kg
Counterweights – Maximum460 kg
Minimum Counterweight Recommendations – Extendible Stick: Loader Bucket – MP0 kg
Minimum Counterweight Recommendations – Standard Stick: Loader Bucket – MP0 kg
Air Conditioning45 kg
Minimum Counterweight Recommendations – Extendible Stick: Loader Bucket – GP460 kg
Counterweights – Base115 kg
Ride Control15 kg
Minimum Counterweight Recommendations – Standard Stick: Loader Bucket – GP115 kg
Operating Weight – ROPS Capacity – Maximum11000 kg
Extendible Stick208 kg
Auto-Shift Transmission96 kg
MP Bucket (1.03 m³/1.3 yd³) – with Fold-over Forks860 kg
Cab – ROPS/FOPSStandard
Total Gross Weight Not to Exceed11000 kg
Operating Weight (estimated) (55 kW/74 hp)8270 kg
MP Bucket (1.03 m³/1.3 yd³) – without Fold-over Forks674 kg
NoteMachine Configuration – 70 kW HRC engine; standard stick hoe; standard cab with A/C; AWD standard shift transmission; 1.03 m3 MP loader bucket; 600 mm standard duty hoe bucket; 340/80-20 and 480/80-26 tires; no counterweight; One Way Aux Lines; AWD Guard; Front Fenders; HD Battery; 80 kg operator; full fuel tank.
Operating Weight (estimated) (70 kW/94 hp)8345 kg
Loader QC185 kg
Counterweights – Mid240 kg
Engine – EU Stage V (Standard)
Stroke120 mm
Bore98 mm
Note (1)Net power advertised is the power available at the flywheel when the engine is equipped with fan, air cleaner, muffler and alternator.
Displacement3.6 l
EngineC3.6 55.4 kW Electronic Turbo Intercooled
EmissionsMeets EU Stage V emission standards.
Net Torque – SAE J1349418 N·m
Torque Rise (net)86% @ 1,200 rpm
Note (2)No derating required up to 3048 m altitude. Auto derate protects hydraulic and transmission systems.
Net Power Rating @ 2,200 rpm – SAE J1349:201152 kW/70 hp
Ratings at 2,200 rpm – Engine Power ISO 14396:200255 kW/75 hp
Ratings at 2,200 rpm – Gross Power SAE J1995:201456 kW/76 hp
Net Power Rating @ 2,200 rpm – ISO 9249:200751 kW/70 hp
Engine – EU Stage V (Optional)
Stroke120 mm
Note (1)Net power advertised is the power available at the flywheel when the engine is equipped with fan, air cleaner, muffler and alternator.
EmissionsMeets EU Stage V emission standards.
Torque Rise (net)43% @ 1,500 rpm
Displacement3.6 l
Net Torque – SAE J1349395 N·m
EngineC3.6 70 kW Electronic Turbo Intercooled
Note (2)No derating required up to 3048 m altitude. Auto derate protects hydraulic and transmission systems.
Bore98 mm
Net Power Rating @ 2,200 rpm – SAE J1349:201164 kW/86 hp
Ratings at 2,200 rpm – Engine Power ISO 14396:200270 kW/95 hp
Ratings at 2,200 rpm – Gross Power SAE J1995:201471 kW/97 hp
Net Power Rating @ 2,200 rpm – ISO 9249:200763 kW/86 hp
Engine – EU Stage V (Optional) – A
Net Torque – SAE J1349436 N·m
Torque Rise (net)48% @ 1,500 rpm
EngineC3.6 74.4 kW Electronic Turbo Intercooled
EmissionsMeets EU Stage V emission standards.
Displacement3.6 l
Note (2)No derating required up to 3048 m altitude. Auto derate protects hydraulic and transmission systems.
Note (1)Net power advertised is the power available at the flywheel when the engine is equipped with fan, air cleaner, muffler and alternator.
Bore98 mm
Stroke120 mm
Ratings at 2,200 rpm – Gross Power SAE J1995:201476 kW/103 hp
Net Power Rating @ 2,200 rpm – SAE J1349:201168 kW/92 hp
Net Power Rating @ 2,200 rpm – ISO 9249:200768 kW/92 hp
Ratings at 2,200 rpm – Engine Power ISO 14396:200274 kW/101 hp
NoteTravel speeds of backhoe loader at full throttle, when equipped with 480/80-26 rear tires.
Transmission – Standard Shift Transmission (Standard)
Forward – 4th40 km/h
Reverse – 1st6 km/h
Reverse – 2nd9 km/h
Forward – 1st6 km/h
Reverse – 3rd21 km/h
Forward – 3rd21 km/h
Forward – 2nd9 km/h
Reverse – 4th40 km/h
Transmission – Powershift Transmission (Optional)
Reverse – 3rd27 km/h
Reverse – 1st6 km/h
Forward – 4th40 km/h
Forward – 2nd10 km/h
Forward – 3rd20 km/h
Reverse – 2nd12 km/h
Forward – 1st6 km/h
Transmission – Auto-Shift Transmission (Optional)
Reverse – 1st6 km/h
Forward – 4th20 km/h
Forward – 3rd12 km/h
Forward – 6th40 km/h
Forward – 1st6 km/h
Reverse – 2nd12 km/h
Forward – 2nd10 km/h
Reverse – 3rd27 km/h
Forward – 5th27 km/h
Transmission – Auto-Shift Transmission with Lock-Up Torque Converter (Optional)
Reverse – 3rd27 km/h
Reverse – 1st6 km/h
Forward – 3rd12 km/h
Forward – 6th40 km/h
Forward – 1st6 km/h
Reverse – 2nd12 km/h
Forward – 5th27 km/h
Forward – 4th20 km/h
Forward – 2nd10 km/h
Rear Axle – Static26500 kg
Front Axle (AWD) – Static23500 kg
Front Axle (AWD) – Dynamic9000 kg
Rear Axle – Dynamic10000 kg
System Pressure – Loader250 bar
System Pressure – Backhoe250 bar
Pump TypeVariable-Flow, Axial Piston
TypeClosed Center
Pump Capacity @ 2,200 rpm160 L/min
AWD Cylinder, One (1) Double Acting – Stroke106 mm
Power SteeringHydrostatic
AWD Cylinder, One (1) Double Acting – Bore65 mm
AWD Cylinder, One (1) Double Acting – Rod Diameter40 mm
TypeFront Wheel
Turning Circle – AWD (inner wheel not braked) – Outside, Front Wheels9273 m
Turning Circle – AWD (inner wheel not braked) – Outside, Widest Loading Bucket11622 m
Rear Axle16 l
Rear Axle – Planetaries1.7 l
Hydraulic Tank42 l
Engine Oil – With Filter9 l
Hydraulic System95 l
Fuel Tank160 l
Cooling System – A/C18 l
Diesel Exhaust Fluid19 l
Front Axle – Planetaries0.7 l
Front Axle11 l
Transmission (Powershift/Autoshift)19 l
Transmission (Standard Shift)18 l
